Chainway CP30 RFID Printer

$878.99

Chainway CP30 is a desktop RFID printer offering thermal and thermal transfer printing. It features a 3.5-inch LCD touch screen, multiple interfaces, and auto-identifies printhead resolutions, enabling fast, accurate printing of RFID tags, barcodes, invoices, and wristbands for diverse industries.

Printer DPI:

Chainway CP30 is a desktop RFID printer offering thermal and thermal transfer printing. It features a 3.5-inch LCD touch screen, multiple interfaces, and auto-identifies printhead resolutions, enabling fast, accurate printing of RFID tags, barcodes, invoices, and wristbands for diverse industries.

RFID 2x1 All-Purpose Tags Basic Tags 500.png Basic Tags 1000.png Basic Tags 2000.png Basic Tags 4000.png Basic Tags 8000.png Basic Tags 10000.png
RFID 2x1 All-Purpose Tags
from $99.00
Tag Pack:
RFID Rat-Tail Tags Dogtail Tags 500.png Dogtail Tags 2000.png Dogtail Tags 4000.png Dogtail Tags 8000.png Dogtail Tags 10000.png
RFID Rat-Tail Tags
from $99.00
Tag Pack:

Device Specifications

  • Printing Method - Thermal transfer / Direct thermal

    Resolution - 203dpi / 300dpi

    Max - 8ips (203dpi) / 6ips (300dpi)

    Max - 108mm (203dpi) / 106mm (300dpi)

    Max - 2,286mm (203dpi) / 1,524mm (300dpi)

  • RFID Tag - UHF RFID, 860-928MHz, EPC C1G2 (ISO18000-6C)

    Types - Continuous Paper, Gap, Black Mark, Punched Hole Label

    Width - 1'' (25.4) - 4.65'' (118mm), include the liner

    Thickness - 0.002'' (60um) - 0.01'' (250um)

    Height - 0.0787'' (20mm) - 9.84'' (250mm)

    Label Roll Diameter - 5'' (127mm) Max

    Core Diameter - 0.5'' (12.7mm), 1'' (25.4mm), 1.5'' (38mm)

  • Types - Wax, Wax / Resin, Resin

    Width - 1.18'' (30mm) - 4.33'' (110mm)

    Length - 984' (300m)

    Core Diameter - 1'' (25.4mm)

  • Engine - M6E-NANO module based on impinj Indy R500 CM510-1 module based on impinj E510

    Frequency - 920-925MHz / 902 928MHz / 865-868MHz

    Protocol - EPCglobal C1G2 (ISO18000-6C) Supports Impinj Gen2X

  • Dimensions - 293mm (L) × 237mm (W) × 180mm (H)

    Weight - 2.9kg / 102.29oz.

    Display - 3.5 TFT Color Touch Panel LCD

    Interfaces - Standard: USB, USB host, Ethernet
    Optional: Wi-Fi, Bluetooth

    Power Supply - External AC / DC switching power adapter, AC 100V-240V / DC 24V / 2A / 48W, Peak 8A

  • Operating Temp - 41℉ (5℃)-104℉ (40℃), humidity 30% to 85% non-condensing

    Storage Temp - -4℉ (-20℃)-122℉ (50℃), humidity 10%-90% non-condensing


Get Started Right Away
Setting Up Chainway CP30 RFID Printer

In this video, we will go over how to set up your printer right out of the box. In our bundle, we include ARC compatible tags shown in the video.

Setting Up Chainway C72 RFID Scanner

In this short video we will go over the pairing process between your Android RFID Scanner and the CP30 RFID Printer.

Printing your first RFID Tags

You’re ready to print your first tags! In this video, we will set up your first EZTag and get it printed! In our bundle, we include ARC compatible tags shown in the video.
