RFIDLinked EPC Decoder RFID Scanner | with Software to Convert EPC Hex to UPC

$598.00

Transforms complex EPC Hex RFID tag data into the encoded UPC barcode number directly onto your Windows computer. The included RFIDLinkedWedge Software (for Windows 11) automatically decodes the SGTIN96 retail RFID tag, and outputs just the UPC to your PC text field. Simply connect the USB RFID scanner to your Windows Computer, install the RFIDLinkedWedge tool, and begin scanning decoded RFID tags directly into your workflow.

Package Details

RFIDLinkedWedge Software decodes raw EPC hexadecimal RFID tag data into readable UPC barcode numbers automatically for simplified RFID workflows.
Sends decoded RFID data into Excel, ERP systems, WMS software, browser fields, POS systems, inventory platforms, and virtually any text field like a keyboard wedge scanner.
Simple corded USB connection for reliable RFID scanning on Windows PCs, laptops, and workstations without complex setup requirements.
Ideal for Walmart RFID compliance, warehouse inventory management, receiving operations, product lookup, RFID testing, and retail supply chain environments.
Eliminates the need to manually interpret confusing EPC hexadecimal RFID tag memory by automatically converting RFID scans into meaningful product identifiers.

Device Specifications

Engine - CM710-1 module based on Impinj E710
Frequency - 865-868 MHz / 920-925 MHz / 902-928 MHz
Impinj Gen2X - Supported
Protocol - EPCglobal C1G2 (ISO18000-6C)
Antenna - Circular Polarized Antenna
Max Read Range - 7-100cm (30cm is recommended)
Dimensions - 154.0 x 87.8 x 65.0mm / 6.46 x 3.43 x 2.56in.
Comm Interface - RJ45 Interface
2D Imager Scanner - Integrated
Min.Resolution - Code 39 – 4mil、UPC – 7.8mil (60%)、 PDF417 – 5mil、Datamatrix – 5mil
Operating Temp - 4 °F to 122 °F / -20 °C to 50 °C
Storage Temp - -40 °F to 158 °F / -40 °C to 70 °C
Humidity - 5% RH - 95% RH non condensing
Drop Specification - Multiple 1.5 m / 4.9 ft. drops to the concrete across the operating temperature range

Get Started Right Away

In this video, we will go over how to set up your printer right out of the box. In our bundle, we include ARC compatible tags shown in the video.

In this short video we will go over the pairing process between your Android RFID Scanner and the CP30 RFID Printer.

You’re ready to print your first tags! In this video, we will set up your first EZTag and get it printed! In our bundle, we include ARC compatible tags shown in the video.
